Description
Download Product Brochure here https://www.erico.com/part.asp?part=LANRJ45C6P
FEATURES
- Rugged, metallic enclosure provides both environmental and electrical shielding
- Up to CAT6 and POE (Power Over Ethernet) protection in one product
- Simple, bi-directional installation
SPECIFICATIONS
| Part Number | LANRJ45C6P |
| Nominal System Voltage (Un) | 48 VDC |
| Max Continuous Operating Voltage (Uc) | 50 VDC |
| Voltage Protection Rating (VPR), L-L | 150 V |
| Voltage Protection Rating (VPR), L-PE | 550 V |
| Nominal Discharge Current (In), L-L | 150 A 8/20 μs |
| Max Discharge Current (In), L-PE | 10 kA 8/20 μs |
| Impulse Current (Iimp) | 1 kA 10/350 μs |
| Rated Load Current (IL) | 1 A |
| Frequency | 250 MHz Max |
| Mounting | 35 mm top hat DIN rail |
| Temperature | -40 to 80 °C |
| Connection Type | RJ45 |
| Enclosure Material | Zinc Alloy |
| Enclosure Rating | IP 20 |
| Depth (D) | 45.5 mm |
| Height (H) | 75 mm |
| Width (W) | 19 mm |
| Complies With | IEC® 61643-21 |
| Certifications | CE, ERICO LANRJ45C6P UL |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285693008 |
| EAN-13 | 0782856930082 |
