Description
Download Product Brochure here https://www.erico.com/part.asp?part=DT2150M
SPECIFICATIONS
| Part Number | DT2150M |
| Nominal System Voltage (Un) | 120 V |
| Max Continuous Operating Voltage (Uc) | 150 V |
| Nominal Discharge Current (In), IEC | 20 kA 8/20 μs |
| Max Discharge Current (Imax), IEC | 50 kA 8/20 μs |
| Nominal Discharge Current (In), UL | 20 kA 8/20 μs |
| Frequency | 50 – 60 Hz |
| Temperature | -35 to 85 °C |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Certifications | CE, ERICO DT2 Series VDE |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285693851 |
