Description
Download Product Brochure here https://www.erico.com/part.asp?part=DSD110M275
SPECIFICATIONS
| Part Number | DSD110M275 |
| Article Number | 702566 |
| Nominal System Voltage (Un) | 220 – 240 V |
| Max Continuous Operating Voltage (Uc) | 275 VAC 350 VDC |
| Nominal Discharge Current (In), Per Mode | 5 kA 8/20 μs |
| Max Discharge Current (Imax), Per Mode | 10 kA 8/20 μs |
| Voltage Protection Level (Up) | 930 V @ 3 kA 1,300 V @ 5 kA |
| Frequency | 0 – 60 Hz |
| Technology | MOV with thermal disconnect |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Status Indication | Mechanical flag |
| Temperature | -40 to 80 °C |
| Module Width | 1 M |
| Depth (D) | 49 mm |
| Height (H) | 45 mm |
| Width (W) | 18 mm |
| Unit Weight | 0.068 kg |
| Certifications | CE |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285658206 |
| EAN-13 | 8711893041620 |
