Description
Download Product Brochure here https://www.erico.com/part.asp?part=DSD11502SR275
FEATURES
- 150kA 8/20μs surge rating provides protection suitable for main distribution panels and provides a long operational life
- Indication flag provides clear visual indication of life status
- Remote contacts provide remote status monitoring
- Simple combinations of the DSD and SGD series allow the protection of TT, TNC, TNC-S and IT systems
SPECIFICATIONS
| Part Number | DSD11502SR275 |
| Article Number | 702420 |
| Nominal System Voltage (Un) | 220 – 240 V |
| Max Continuous Operating Voltage (Uc) | 275 VAC 350 VDC |
| Nominal Discharge Current (In) | 60 kA 8/20 μs |
| Max Discharge Current (Imax) | 150 kA 8/20 μs |
| Voltage Protection Level (Up) | 850 V @ 3 kA 1,600 V @ 60 kA |
| Impulse Current (Iimp) | 25 kA 10/350 μs |
| Frequency | 0 – 60 Hz |
| Protection Modes | Single |
| Technology | MOV with thermal disconnect |
| Connection, Solid | 35 mm² Max |
| Connection, Stranded | 25 mm² Max |
| Mounting | 35 mm top hat DIN rail |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Enclosure Rating | IP 20 NEMA®-1 |
| Status Indication | Mechanical flag |
| Terminal Torque | 3.5 N-m Max |
| Remote Contacts | Yes |
| Temperature | -40 to 80 °C |
| Module Width | 2 M |
| Depth (D) | 68 mm |
| Height (H) | 90 mm |
| Width (W) | 36 mm |
| Unit Weight | 0.33 kg |
| Complies With | ANSI®/IEEE® C62.41.2-2002 Cat A, Cat B, Cat C ANSI®/IEEE® C62.41.2-2002 Scenario II, Exposure 3, 100 kA 8/20 μs, 10 kA 10/350 μs IEC® 61643-1 Class I, Class II |
| Certifications | CE |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285647028 |
| EAN-13 | 8711893013801 |
