Description
Download Product Brochure here https://www.erico.com/part.asp?part=DEPRS23299D
FEATURES
- Models to cover RS-232, RS-423, RS-422 and RS-485 protocols
- Designed to provide both line to signal-ground and signal-ground to protective-earth protection
- Plug-in protection is simple to install
SPECIFICATIONS
| Part Number | DEPRS23299D |
| Nominal Discharge Current (In) | 300 A 8/20 μs |
| Max Continuous Operating Voltage (Uc) | 15 VDC |
| Capacitance | 30 pF Max |
| Protection Modes | All pins to ground |
| Connection Type | DB9, Male/Female |
| Depth (D) | 61 mm |
| Height (H) | 16.6 mm |
| Width (W) | 30.5 mm |
| Unit Weight | 0.054 kg |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285661015 |
| EAN-13 | 8711893096804 |
